Equipment

Nano Mechanical System

Short Description: The TI Premier makes nanoscale mechanical and tribological characterization simple and consistent.Read more



SmartLab X-Ray Diffractometer (XRD)

Short Description:

Control Software:

SmartLab Guidance: Used to control SmartLab and perform measurements.

Data processing software:

  • Standard  data processing: performance basic data such as smoothing, background removal ,etc.
  • PDXL: Perform basic data processing

Analysis software :

  • PDXL(9240J702,9240J703, 9240J710): perform the addition functions such as Phase ID analysis, Quantitative Analysis, Rietveld analysis, etc.
  • GlobalFit:Performs Reflectivity analysis
  • NANO-Solver:Performs particle size/pore diameter distribution analysis.
  • Pore Size analysis: Performs analysis of particle size/pore diameter distyribution of thin film, accounjting for diffuse scattering from surface and interface.
  • GlobalFit (extended rocking curve analysis 9240H145): Performs simulation and anaylsis of rocking curve.
  • QA-Tex(9240H601): Performs quantitative analysis of the preferred orientation of a sample.
  • CSDA(9240H651): performs crystallite size distribution analysis.Read more

XRD

Scanning Elelctron Microscope

Short Description: Hitachi 3600 N Scanning electron microscope with a 5 axis motorized stage coupled with ultra dry Compact EDS Detector Read more

SEM

The Litesizer™ 500 Particle Size Analyzer

Short Description: The Litesizer is an instrument for characterizing nano and microparticles in dispersions and
solutions.

PSA

Anton Paar MCR 102 Rheometer

 Short Description: A Rheometer is a laboratory device used to measure the way in which a liquid, suspension or slurry flows in response to applied forces.

Rheometer

Raman Spectroscope

Short Description:inVia Raman microscopes from Renishaw are high-sensitivity systems with integrated research grade microscopes, enabling high resolution confocal measurements. inVia Raman microscopes support multiple lasers, with automatic software switching of excitation wavelength

 TGA/DSC

 Short Description:TGA/DSC measures the mass of the sample and energy absorbed as it is heated or cooled.Read more



Planetary Ball Mill – “Mill pulverisette 5”

Short Description:The laboratory planetary mill "pulverisette 5" can be used universally for high-speed grinding of liquid or solid inorganic and organic samples for analysis, quality control or material testing.Read more



CHNS Analyzer



Short Description:CHNS elemental analyzers provide a means for the rapid determination of carbon, hydrogen, nitrogen and sulphur in inorganic matrices and other types of materials.


 ITECH make 750VA AC Power Supply

 Short Description:Output frequency:10Hz-5kHz,Maximum Output voltage: 300 Vrms,Resolution 10 mV,RMS Current: 3 A at 300 V, 6 A at 150 V,Peak Current: 9 A at 300 V, 18 A at 150 V,More units can be combined to delivery higher current and 3-phase operation.

Multi Target Sputtering System

Short Description:

 The MiniLab 060 standard configuration includes a turbo molecular pump positioned on an ISO160 port at the rear of the vacuum chamber. The vacuum chamber sits on a double-rack frame that contains all system control electronics and power supplies. MiniLab 060 system is available with load-lock facility.

 MTSS

Field Emission Scanning Electron Microscope (FESEM)

Short Description:

Field Emission Scanning Electron Microscopes (FESEM) scans a sample with a focused electron beam and gives images with information about the samples’ topography and composition.

  • High resolution surface sensitive information and materials contrast.
  • Widely used in nanotechnology, materials research, life sciences, semiconductor, raw materials and industry.
  • Magnification:- 100-20,000,00X
FESEM Image

3-AXIS LASER SYSTEM FOR SURFACE TEXTURING

Short Description:

Laser Unit , 3-Axis Laser System with Dual Heads, Machine Specifications, Electrical Power Requirement                110/220 VAC, Operating Temperature     10°C-35°C, Operating Humidity  5%-95%

Cooling Air cooled, Marking Area                60 x 60 mm (For laser source 1) and 100x100 mm (For laser source 2), Marking preview               -              Gives the operator the chance to preview the pattern and adjust the component according., -                Highly recommended for error proof laser operation.

Red pointer (useful to fine tune laser focus)       -              Useful when laser operations need to be performed on different components which differ in thickness & shape.
