SOLID MECHANICS LABORATORY
The Solid Mechanics Laboratory is an essential facility dedicated to conducting experimental research and providing technical expertise in the field of solid mechanics. From testing the strength of steel specimens to analyzing the behavior of different structures under load, this laboratory serves as a hub for hands-on learning and innovation. The laboratory provides students with the opportunity to explore the basic properties of structural materials and the behavior of simple structural elements and systems through a series of practical experiments
Facilities |
Images |
Advance Universal Testing Machine (UTM)
Name of Machine
|
Make
|
Experiments (ASTM)
|
Temp. Range
|
Load Capacity
|
Advance Universal Testing Machine (UTM)
|
Tinius Olsen
100ST
|
Tensile (E08)
|
Environmental Chamber:
-70°C to 300°C
|
100 KN
|
Furnace: upto 1100°C
|
|
![Advanced UTM](Mechanical Engineering/Advance_Universal_Testing_Machine_(UTM).jpg) |
Impact Toughness Testing Machine
Make
|
Experiments (ASTM)
|
Pendulums
|
Temp. Range
|
(w + b)
walter + bai ag
|
Charpy Test (E23)
|
Angle 0° to 160°
Speed 5.6 m/s
Length 790 mm
Max. Energy 450 J
Weight 297 N
|
Room Temp.
|
|
![Impact Testing Machine](Mechanical Engineering/Impact_Testing_Machine.jpg) |
Optical Microscope
Make
|
Experiments
|
Temp. Range
|
Resolution
|
Novel Optics
|
Microstructure Analysis
|
Room Temp.
|
upto 600X
|
|
![Optical Microscope](Mechanical Engineering/optical_microscope.jpg) |
Rockwell and Brinell Hardness Tester
Make
|
Experiments (ASTM)
|
Temp. Range
|
Load Range
|
Tinius Olsen |
- Rockwell Hardness (E18)
- Brinell Hardness (E10)
|
Room Temperature |
2.5 kgf to 187.5 kgf
|
|
![Rockwell and Brinell Hardness Tester](Mechanical Engineering/Rockwell_and_Brinell_Hardness_Tester.jpg) |
Vicker’s Microhardness Tester
Make
|
Experiments (ASTM)
|
Temp. Range
|
Load Range
|
Resolution
|
Tinius Olsen
|
|
Room Temperature
|
0.01 kgf to 2 kgf
|
upto 600X
|
|
![Vicker’s Microhardness Tester](Mechanical Engineering/Vicker’s_Microhardness_Tester.jpg) |
Torsion Testing Machine
Temp. Range
|
Load Capacity
|
Room Temp.
|
100 KN-m
|
|
![Torsion Testing Machine](Mechanical Engineering/Torsion_Testing_Machine.jpg) |
Servo Hydraulic Fatigue Testing Machine
Make
|
Experiments (ASTM)
|
Temp. Range
|
Load Capacity
|
(w + b)
walter
+ bai ag
|
|
-70°C to RT
|
100 KN
(min 0.5 KN)
|
- High Cycle Fatigue (E606)
|
-70°C to RT
|
- Fatigue Crack Propagation (E647)
|
RT to 600°C
|
- Fracture Toughness KIC (E399)
- Fracture Toughness JIC (E1820)
|
|
![Servo Hydraulic Fatigue Testing Machine](Mechanical Engineering/Servo_Hydraulic_Fatigue_Testing_Machine.jpg) |
